Thermofoil Underfloor Heating – Mat Only

Electric foil heating system

Bring the luxury feeling of underfloor heating and the simplicity of an electric system to timber and carpet floors.

Thermofoil PRO is the most advanced electric under floor heating foil available today. Innovations such as our exposed cable loops and continuous earth protection ensure an easy installation and total safety.

  • Lifetime warranty

    We are so confident in the quality of Thermofoil Pro that we give each system a warranty that lasts a lifetime with 3 year warranty on the thermostats.

  • Efficient heat exchange foil

    The double layer of foil in Thermofoil PRO is specifically designed to protect the heating element and achieve an even spread of heat to the floor above.

  • Easy cut and return installation

    The accessible cable loops are an example of Thermogroup’s product innovations. They make cut and return installation quick and easy while protecting the heating element.

  • Continuous earth protection braid

    Electrical safety is paramount and Thermofoil PRO’s continuous earth braid protection runs the entire length of the heating cable. You can even install it in a bathroom.

  • Minimal height build-up

    The foil system is only 2.5mm thick with a low profile cold tail of only 4mm thick, which can be concealed within the insulation.

Select heating mat & accessories to fit your space

Thermofoil underfloor heating foil

Stock No.
121402
Size
2 x 0.5m
Area
1m²
Output
140 W
Resistance
337.9 Ω
Price
$329.00
Stock Status
Low Stock
Stock No.
121403
Size
3 x 0.5m
Area
1.5m²
Output
210 W
Resistance
251.9 Ω
Price
$389.00
Stock Status
In Stock
Stock No.
121404
Size
4 x 0.5m
Area
2m²
Output
280 W
Resistance
188.9 Ω
Price
$419.00
Stock Status
In Stock
Stock No.
121405
Size
5 x 0.5m
Area
2.5m²
Output
350 W
Resistance
151.1 Ω
Price
$489.00
Stock Status
In Stock
Stock No.
121406
Size
6 x 0.5m
Area
3m²
Output
420 W
Resistance
126 Ω
Price
$569.00
Stock Status
In Stock
Stock No.
121408
Size
8 x 0.5m
Area
4m²
Output
560 W
Resistance
94.5 Ω
Price
$739.00
Stock Status
In Stock
Stock No.
121410
Size
10 x 0.5m
Area
5m²
Output
700 W
Resistance
75.6 Ω
Price
$859.00
Stock Status
In Stock
Stock No.
121412
Size
12 x 0.5m
Area
6m²
Output
840 W
Resistance
63 Ω
Price
$909.00
Stock Status
In Stock
Stock No.
121414
Size
14 x 0.5m
Area
7m²
Output
980 W
Resistance
53.9 Ω
Price
$969.00
Stock Status
In Stock
Stock No.
121416
Size
16 x 0.5m
Area
8m²
Output
1120 W
Resistance
47.2 Ω
Price
$1,105.00
Stock Status
In Stock
Stock No.
121418
Size
18 x 0.5m
Area
9m²
Output
1260 W
Resistance
41.9 Ω
Price
$1,249.00
Stock Status
In Stock
Stock No.
121420
Size
20 x 0.5m
Area
10m²
Output
1400 W
Resistance
37.8 Ω
Price
$1,429.00
Stock Status
Low Stock
Stock No.
121424
Size
24 x 0.5m
Area
12m²
Output
1680 W
Resistance
31.5 Ω
Price
$1,639.00
Stock Status
In Stock
Remember to order your chosen Thermofoil system, a Thermostat and suitable underlay and overlay for the floor build-up

Installation accessories

Stock No.
5400
Description
Econosoft Underlay
Size
1.2 x 0.5m
Area
6m²
PK Qty
10
Price
$179.00
Stock Status
In Stock
Stock No.
5421
Description
Econosoft Acoustic Barrier
Size
10 x 1m
Area
10m²
PK Qty
1
Price
$315.00
Stock Status
In Stock
Follow this link for further information regarding Econosoft Underlay and Overlay

Technical Data

Width
500mm
Thickness
2.5mm
Max. Temperature*
28°C *
Protection Rating
IPX7
Warranty
Lifetime
Voltage
240Volts
Wattage
140W/m²
Conductor Type
Single Ended
Cold Tail Length
5m
*Regulated by floor sensing thermostat

Frequently Asked Questions


What is the best Underfloor Heating system for my application?

If you are unsure which floor heating system best suits your needs or daunted by the many options and offerings on the market, Thermogroup's online underfloor heating system selector tool can help you make the best decision. Our underfloor heating selector takes you through a simple four step process to determine the most suitable underfloor heating system for your individual application then also lists out all the products required to get the job done, so you can be assured that you will have everything required when it comes to installation. If you have any requirements outside of those specified on the tool do not hesitate to contact us to discuss your requirements.

Try the Heating System Selector
